Mount kits include mount bracket, fasteners and safety cable. Standard brackets are fabricated from cold-rolled carbon steel.

H-Mountmount kits H-Mount

The “H” is the standard weld-on mount for bins and hoppers. All units are available in stainless steel and aluminum as well as standard cold-rolled steel.


high temp adaptor bracketsStand-Off High Temp & Adaptor Brackets

These brackets were developed with two applications in mind:

  • Retrofit new vibrators to existing mounts without having to weld.
  • High temperature applications where the vibrators must be located away from the heat source.

Glue mount bracketsMartin® Glue Mount System

Can’t weld on a bracket? Try the glue mount. Try the unique MARTIN® GLUE-MOUNT™System. Special brackets are designed to be used with our high-performance, two-component adhesive. Simply clean the surface, apply the glue to the bracket, and hold in place for 10 minutes. The bracket will be ready for use in 24 hours. This mount is best used on flat surfaces with the MARTIN® PKL™ Interval Impactors.






MARTIN® NTS NON-IMPACTING LINEAR VIBRATORS
VIBRATOR BRACKET
NTS 350 36189-MB18
NTS 78/01 32602-MB18
NTS 50/01 32603-MB18
NTS 54/02 32604-MB30
MARTIN® PKL™ INTERVAL IMPACTORS
VIBRATOR BRACKET
PKL 450 32537-MB12
PKL 740 32541-MB12
PKL 2100 32543-MB18
PKL 2100 32544-MB18
PKL 5000 32546-MB18
MARTIN® NCT™ TURBINE VIBRATORS
VIBRATOR BRACKET
NCT-5 61004-MB18
NCT-10 61005-MB18
NCT-10i 61006-MB18
NCT-15 61007-MB24
NCT-29 61008-MB24
NCT-29i 61009-MB24
NCT-55 61010-MB30
NCT-108 61011-MB30
NCT-108i 61012-MB30
NCT-126 61013-MB36
NCT-250 61014-MB36
NCT-250i 61015-MB36
VIBRATOR MOUNT BRACKET DIMENSIONS
A B C D E F G
MB-12
XHA-0.5, 1.5 12(305) 5.5(140) 6(152) 5(127) 0.25(6) 1.5(38) 0.25(6)
XHD-1.5 12(305) 5.5(140) 6(152) 5(127) 0.25(6) 1.5(38) 0.25(6)
PKL 450, 740 12(305) 5.5(140) 6(152) 5(127) 0.25(6) 1.5(38) 0.38(10)
MB-18
XHA-0.5, 1.5, 2T 18(457) 5.5(140) 6(152) 5(127) 0.25(6) 1.5(38) 0.38(10)
XHD-1.5, 2.5T 18(457) 5.5(140) 6(152) 5(127) 0.25(6) 1.5(38) 0.38(10)
NTS 350, 75/01, 50/01 18(457) 5.5(140) 6(152) 5(127) 0.25(6) 1.5(38) 0.38(10)
PKL 2100, 5000 18(457) 5.5(140) 6(152) 5(127) 0.25(6) 1.5(38) 0.38(10)
NCT-5, 10, 10i 18(457) 5.5(140) 6(152) 5(127) 0.25(6) 1.5(38) 0.38(10)
MB-24
NCT-15, 29, 29i 24(610) 6(152) 6(152) 5(127) 0.25(6) 1.5(38) 0.38(10)
MB-30
XHA-3.5, 6.5, 8.5T 30(762) 7.25(184) 7.5(191) 6.5(165) 0.38(10) 1.5(38) 0.38(10)
XHD-5, 6.5, 8T 30(762) 7.25(184) 7.5(191) 6.5(165) 0.38(10) 1.5(38) 0.38(10)
NTS 54/02, 50/04 30(762) 7(178) 7.5(191) 6.5(165) 0.25(6) 1.5(38) 0.38(10)
NCT-55, 108, 108i 30(762) 7(178) 7.5(191) 6.5(165) 0.25(6) 1.5(38) 0.38(10)
MB-36
XHA-11.5T 36(914) 8.75(222) 11(279) 8(203) 0.38(10) 1.5(38) 0.5(13)
XHD-12, 16T 36(914) 8.75(222) 11(279) 8(203) 0.38(10) 1.5(38) 0.5(13)
NCT-126, 250, 250i 36(914) 8.75(222) 11(279) 8(203) 0.38(10) 1.5(38) 0.5(13)
inches(mm)

E-Z™ Vibrator Mount Kit Spec Sheet Download
